COSINA

COLOR-SKOPAR 28mm F2.8 Aspherical (L39)

Cutting-edge optics in a compact exterior

Features

High-performance wide-angle lens focused on light handling on rangefinder camera.
The latest optical design and aspherical element made the lens with as same optical performance as our ULTRON Vintage Line 28mm F2 Aspherical VM-mount lens, while keeping the maximum aperture at F2.8 for extremely compact styling.
L (L39) mount is adopted and the lens has a nostalgic and tasteful appearance and is made of brass for the exterior.


This product was discontinued in July 2024.

Main Features

φ39mm screw mount

A universal mount that emerged in the 20th century, the φ39mm screw mount is used. It can be attached to any rangefinder camera that uses the same standard.

Compact & high performance

By adopting an aspherical lens, it demonstrates excellent optical performance even when the aperture is wide open. The total length of the product is 22.5 mm (from the mount surface), it does not protrude into the viewfinder frame when used on a rangefinder camera, and handling feels also good.

Two types of exterior to choose from

The exterior is made of brass and comes in two types: silver and black paint. On the black painted model, even the mount is finished in black. And the focus lock button, focus lever, and infinite / short-distance stopper are nickel-plated to add an accent to the design.

Dedicated lens hood included

The lens comes with a dedicated aluminum screw-in hood and an aluminum cover-type front cap to provide not only shading performance but also design compatibility with the lens body. (The black painted type comes with a painted hood and front cap.)

Manual focus for reliable focus operation

By adopting an all-metal helicoid unit processed and adjusted with high precision and high-quality grease that produces an appropriate torque, focusing with a smooth operation feeling is realized. It enables fine focus adjustment.

Equipped with a rangefinder interlocking system

The high-precision rangefinder interlocking mechanism enables severe focusing near the maximum aperture. The shortest shooting distance linked to the rangefinder is 0.7m.

Full frame image circle

The lens secures a generous image circle that supports full-frame format. In addition, it achieves a very compact style compared to interchangeable lenses for single-lens reflex cameras.

Specifications

Lens diagram

Focal Length
28mm
Aperture Ratio
1 : 2.8
Minimum Aperture
F22
Lens Construction
5 groups 8 elements
Angle of View
74.6°
Aperture Blade
10
Minimum Focus
0.7m
Rangefinder Coupling
∞~0.7m (It depends on the camera)
Diameter × Length
φ47.0×22.5mm
Filter size
φ34mm
Weight
122g
Hood
With Standard hood

EAN

Ean Code
EAN 4002451 006408 (Silver)
4002451 006415 (Black paint)

Examples

  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
  • COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
Voigtländer COLOR-SKOPAR 28mm F2.8 Aspherical L(L39) PHOTO BY Mitsuru Kano
PHOTO_01
PHOTO_02
PHOTO_03
PHOTO_04
PHOTO_05
PHOTO_06
