COLOR-SKOPAR 50mm F2.2
Features
With a maximum aperture of F2.2, the lens is a standard lens with a focal length of 50 mm, yet its overall length from the mount surface is a mere 30 mm. 7 elements in 6 groups, including 3 elements of anomalous partial dispersion glass, provide excellent optical performance from a maximum aperture of F2.2. Compact and highly mobile, this lens is ideal for all-round use.
Main Features
Compact style
The overall length from the mount surface is reduced to 30 mm and the filter diameter is the traditional size of ø39 mm. It has a compact appearance that is highly portable and easy to take in and out of a bag.
Focusing tab for ease of operability
The focusing tab is shaped to fit your finger to ensure fast and precise focusing.
Minimum focus distance of 0.5 meters
The lens focuses beyond the minimum rangefinder-coupled focus distance of 0.7m all the way down to 0.5m. This feature is especially useful when using the lens on a camera with a live view function.
Dedicated hood included.
A compact, straight-type hood with a shape that does not interlap the rangefinder camera's rangefinder frame is included.
Manual focus for reliable focusing
Employs a very precisely machined and adjusted all metal helicoid unit lubricated with high quality grease to realize smooth focusing operation with just the right amount of torque. This enables very precise focusing.
Bayonet type VM mount
Uses the VM-mount lens mount compatible with Leica M-mount. Not only can this lens be used on rangefinder-coupled cameras, but design-wise it also balances very nicely when mounted on mirrorless digital cameras with a mount adapter.
Installed with a focus-coupling system
The high-precision rangefinder coupling mechanism enables precise focusing in focus critical situations such as when shooting at or close to maximum aperture.
Imaging circle that covers full frame format
The lens features a generous imaging circle that covers the 35 mm full frame format. Furthermore, its size is extremely compact compared to interchangeable lenses for single-lens reflex cameras.
Specifications
Lens diagram
- Focal Length
- 50mm
- Aperture Ratio
- 1 : 2.2
- Minimum Aperture
- F16
- Lens Construction
- 6 groups 7 elements
- Angle of View
- 47.3°
- Aperture Blade
- 10
- Minimum Focus
- 0.5m
- Rangefinder Coupling
- ∞～0.7m (It depends on the camera)
- Diameter × Length
- φ51.4×30.0mm
- Filter size
- φ39mm
- Weight
- 135g
- Hood
- With Standard hood
- Color
- Silver / Black
EAN
- Ean Code
- EAN 4002451 007412(Silver)
4002451 007412(Black)
Examples
-
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura -
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura -
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura -
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura -
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura -
COLOR-SKOPAR 50mm F2.2 PHOTO BY Tetsu Sawamura
